Two-stage reduction transmission structure, with optional standard differential and No-Spin anti-skid differential.
Gleason spiral bevel gears are adopted for the main reduction, featuring high transmission efficiency and low noise.
Wheel-end NGW planetary reduction transmission structure with reasonable and compact design.
Caliper disc brake, providing large braking torque, reliable and responsive.
Suitable for ZL50 series loaders.
Note: Specifications and designs are subject to change without notice.
| Parameters | ZL50MBQ | ZL45 | TL46 |
| Total transmission Ratio | 22.85 | ||
| Maximum input torque | 5100N·m | 5000N·m | 5000N·m |
| Load each axle | 27000 Kg | 25000 Kg | 25000 Kg |
| Braking oil pressure | 11 MPa | ||
| Braking moment | 13050N·m | ||
